Medical Facility Waste Monitoring

Hospital Waste Management as well as Competitive prices as Pakistan is a competitive market. We have a complete setup with Office, Customer Relations, Import / Export, Biomedical Department, Application Support Department & Project Designing Department.Description        Minimum Requirements
Design standard    Multiple chamber incinerator to the design of EPA  standards, Air pollution control
Description of the Chimney    Top mounted, self supporting
Incinerator performance    150kg/hr
Refuse     Hospital waste and carcasses
Recommended Temperatures    Minimum 1000⁰C
Dimensions:
Length
Width
Height
Extra width for burners    At least 3000mm
Loading door opening    Minimum 700mm x 600mm
Hearth area    5.00square meters
Description or grate/hearth    A full hearth supplied to prevent contaminated liquids from flowing into the ash pit without being incinerated
Primary chamber volume    At least 3 cubic meters
Mixing chamber volume    At least 1 cubic meters
Settling chamber volume    At least 3 cubic meters
Weight excluding chimney    15, 000kg at manufacture
Firing tools supplied    Hoe, Poker and rakeMaterial of construction    Case – 5mm mild steel.
Bracing – Heavy angle and channel.
Hearth – 1550⁰C castable general purpose high strength, high abrasion resistant monolithic refractory concrete.
Ashing door – High grade cast iron.
Loading door – 5mm mild steel lined with 1550⁰C castable  general purpose high strength, high abrasion resistant monolithic refractory concrete.
Refractory  concrete:
Alumina content of refractory
Refractory thickness
Minimum 49%
At least 127mm.
Insulation  to walls     1000⁰C Castable insulation
Chimney stack:
Chimney
Height from base    3.5 mm mild steel
9 meters above ground level and clear the highest point of the building by not less than 3 meters
At least 560mm
At least 750Kg
Controls:
Draught

Air supply

Electric

Barometric indicator, door operated draught limiter

Built-in forced heated air ducts, primary and secondary (intensifier)
Control panel – Circuit breakers, main switch, timer, pilot lights, 2 set point pyrometer and one set point pyrometer.
Electricity supply required    415 Volts Three phase.
Auxiliary  fuel    Electrically operated only
Emission     Multiple chamber design with inbuilt emission control
Paint: Case and stack    400⁰C Heat Resistant Grey
Temperature of case    100⁰C

WASTE BROCHURES As Well As CONTAMINATED MATERIALS LIST

1 Burner 30 =KG burn/h and also it need to have a Scrubber.

2 Burner should have Electric Plastic Shredder for cutting of glass container, surange of Medication.

3 Burner need to have Electrical Car Clave or Microwave for Dis Infection independently with burner.
4 Incinerator needs to have Double Chambers initially Chamber should provided 800C temperature level as well as additional Chamber working 1200C temperature level.
5 Incinerator in out place must have a Specification to show internal temperature level of incinerator.
6 Burner has to operate in 2 systems Electric and also fuel explain in which type of fuel jobs.
Note we want it works on gasoline and also electrical also.for a small pig slaughterhouse task in Vietnam we are looking for a.
solution to ruin securely inedible and confiscated pet items.

As the slaughtered pigs are consumed by more than 90% (from hooves to.
head, blood, etc) the waste volume is fairly tiny also in.
slaughter-points with as much as 100 slaughtered pigs each day.

Although using meat and also bone meal is not banned in Vietnam the.
small quantities of waste do not seem to warrant the installment of a.
rendering system, not also of a batch stove, so incineration seems to be.
the very best option.

I wish to get even more technological details e.g. gas usage for.
blazing 100/200 kg of animal items per day as well as also the FOB.
cost of the unit.The types of waste to be treated are (after EUROPEAN WASTE BROCHURE AND CONTAMINATED MATERIALS CHECKLIST, 2002):

18 01 01 sharps (other than 18 01 03)

18 01 02 body components and organs including blood bags and also blood maintains (other than 18 01 03)

18 01 03 * wastes whose collection and also disposal undergoes special needs in order to avoid infection

18 01 04 wastes whose collection as well as disposal is not subject to unique requirements in order to protect against infection (for example dressings, cast, linen, disposable clothes, baby diapers)

18 01 06 * chemicals containing or consisting of unsafe compounds

18 01 07 chemicals besides those stated in 18 01 06

18 01 08 * cytotoxic as well as cytostatic medications

18 01 09 medications aside from those discussed in 18 01 08

18 01 10 * amalgam waste from dental treatment

dispose Medical waste IV

the incinerator can be made use of to get rid of Medical waste IV, used needles, made use of syringes, scalpels, used dressing material, individual safety devices like gown, gloves and so on truncated body parts, excreta from clients and also various other research laboratory waste.incineration devices that can handle a mix of clinical as well as contaminateds materials. The clinical wastes consist of (yet are not limited to) materials contaminated with blood, physical liquids, feces, and also human tissue/organs from surgical treatment. The dangerous compounds include (however are not limited to): xylene, toluene, chloroform, methylene chloride, trichloroethylene, acetonitrile, formaldehyde wastes, radiation treatment wastes (e.g., Chlorambucil, Cytoxin, Daunomycin, and so on) radiology wastes (e.g., glutaraldehyde), and mercury-containing compounds.includes amputated body parts, body fluids including contaminated blood, blood items, excreta from people, cultures of transmittable infections as well as various other research laboratory wastes e.t.c.
Medical might also consist of used needles, made use of syringes, made use of, expired or infected clothing products like plasters, plasters and plastics, e.t.c. The Burners ought to likewise enable disposal of other wastes created in healthcare facility environment.Technical Requirements for Portable Incinerators

The Chamber volume of around 0.37 m3 and also a.
1 combustible lots quantity (quantity of material) of.
around 0.30 m3

2 Burner power of around 189,000 kcal/hour.
Optimum Burning Temperature Level of approximately 1250

Degree Celsius.
Kind of sent out Gas: Inert as well as zero ecological air pollution effect.
Electric Power: 220V/50 or 60 Hertz

Fuel: Diesel

Electric intake of roughly: 0.35 kw/hr

Gas usage variety: 7 – – 11 ltrs/hr

Controls: Incinerator control including control panel, timer, display screen for keeping an eye on combustion temperature level, system mistake display screen, and so on
. Packaging/Installation: Burner completely set up as well as all set to be connected in power source

User’s manual: Bundle has to be given with user’s manual including described information to installment, procedure, upkeep, analysis of problem shooting signals and also contact telephones. numbers/emails of neighborhood or abroad supplier’s specialists that can be called for assistance on procedure of the devices, if required.

training guide/manual on a compact disc including a demonstration for installment, operation and also. maintenance, in addition to safety standards, etc.

Scope of Supply: Bundle needs to be supplied including. all the called for devices for installation and also must. consist of spare parts/consumables that are needed for a. one year period at a burning rate of approximately 8 hrs. daily

Guarantee must be provided for a 5-years period. beginning with the burner’s setup and. consisting of the arrangement of accessories as well as.
consumables
